AN-322 Additional XY Plotter Functions
Additional functionality has been added to the Trio Motion Coordinator system software (in v2.0254) to ease the programming of XY plotter systems:
- PLOT_CALC function – Calculates the change in direction and estimates the radius of a pair of vectors
