AN-328 FRAME 28 - XYZ Robot with 2 Axis wrists
FRAME 28 transformation allows an XYZ Robot with 2 axis wrist to be easily programmed.
The FRAME 28 transformation is available for MC4XX controllers (including MC464, EURO408 and MC405) with the Robotic Function FEC (feature enable code) fitted
